TSB
Shredder for stalks, straw, open field crop residues
TSB is a Berti mulcher designed for handling grass, stalks, maize, vegetation residues, sugar cane, pineapple plants, sorghum and cover crops, working with materials with a maximum diameter of up to 8 cm. It can be used with tractors with power ratings between 60 and 140 HP and is available in working widths of 160, 180, 200, 220, 230, 250 and 280 cm. It comes standard with a double casing to ensure strength and robustness even in demanding conditions.
The category II three-point hitch is fixed, while on the 230 cm model it can be moved to two positions, offering greater flexibility of use. The rear bonnet can be opened for quick inspections and easy maintenance, ensuring continuous and safe operation.
The rotor can be equipped with 2YT or 3YT knives, or with T hammers, all fitted with bolted counter-knives, for uniform and effective shredding of even the most stubborn residues.
To meet different operational requirements, it is possible to integrate support skids, rear levelling roller, chain and rubber front guards, refinement kit and road signage kit on request, making the TSB a complete, versatile and professional solution for agricultural waste management.
STANDARD EQUIPMENT
- Fixed 3-point linkage, Cat. II.
- 3-point linkage Cat. II, adjustable in two positions (230)
- Top link tie rod.
- Double chassis.
- Free wheel in the gearbox.
- Rear roller Ø 194, height adjustable, with scraper.
- Rear hood opens for inspection.
- BERTI blades “2YT”, “3YT” or Berti hammers type “T”.
- Counter blades, bolted.
- PTO 540 rpm. (160 – 230).
- PTO 1000 rpm (250 – 280).
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Skids kit, height adjustable, with anti-wear shoe
- Heavy duty rear roller Ø 194, with bolted end bearing housings
- Heavy duty rear roller Ø 220, with bolted end bearing housings (250-280),
- Kit rubber steering wheels (2x) with automatic spring locking
- Front protectors with chains
- Kit pruning’s shredding max. 7-8 cm (160-230)
- Input shaft 1”-3/4 Z6 in the gearbox, PTO 540 rpm (280)
- Input shaft 1”-3/4 Z6 in the gearbox, PTO 1000 rpm (280)
- Electronic hour meter, vibration
- Kit road-warning panels with lights
- PTO drive shaft 60/800 N
- PTO drive shaft 60/1000 N
- PTO drive shaft 80/1000 N
- PTO drive shaft 80/1000 N 1”3-4 Z6 mulcher side – 1”3/8 tractor side (280)
cutting tools
