LAND/P
Shredder for stalks, straw, open field crop residues
The LAND/P is a mulcher designed for handling grass, stalks, corn, vegetation residues, sugar cane, pineapple plants, sorghum and cover crops up to 8 cm in diameter, designed for those looking for power, robustness and reliability over large areas. Suitable for tractors with power ratings between 120 and 300 HP, it is available in working widths of 400, 500 and 600 cm.
The machine is built with a double Strenx frame, double transmission, automatic belt tensioners and levelling rollers with bolted bell-type roller cleaners. The floating hydraulic jacks are equipped with safety valves, while the front chain guards ensure maximum safety during operation.
The rotor can be equipped with Berti 2YT2 and 3YT2 universal blades or with T2 type hammers, all equipped with screwed counter blades. The LAND P is also optimised for road transport, thanks to its safety hooks and rear protection bar, allowing for quick and safe movement between different work areas.
On request, it is possible to integrate the Speedy wire cutter, skids, a kit of 4 rubber steering wheels, a second row of bolted counter blades, double centrifugal clutch and hydraulic opening and closing of the bonnets, making the LAND P a complete, versatile and professional solution for managing large crops and agricultural residues.
STANDARD EQUIPMENT
- Fixed 3-point linkage, Cat. II-III.
- Top link oscillating rod.
- Double chassis.
- Double transmission.
- Free wheel in the gearbox (1”-3/4, Z6, input shaft).
- Full automatic belt tensioners.
- Rear levelling roller (pair) Ø 194 with scraper (400).
- Heavy duty rear rollers Ø 220, with bolted end bearing housings, and scrapers (500-600).
- Floating system on the hydraulic cylinders.
- Safety hooks for transport on road.
- Covers of side-transmissions made of steel.
- Front protectors with chains.
- Counter blades, bolted.
- Rear hoods open for inspection.
- BERTI blades “2YT2”, “3YT2” or Berti hammers type “T2”.
- Rear lights bar, for travel on road.
- PTO 1000 rpm.
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Hydr. Mulcher SPEEDY, rear mount with floating system, for grass strip cut
- Skids kit, height adjustable, with anti-wear shoe
- Heavy duty rear roller Ø 194, with bolted end bearing housings, scraper (400)
- Kit 4x steering wheels 10.0/75 R 15.3 with integrated parking stand
- Second line of counter-blades, bolted
- Hydraulic cylinder for adjustment of hood’s position
- Centrifugal clutch (BERTI design)
- Electronic hour meter, vibration
- Parking stand for machine folded-up (only for version with rollers)
- PTO drive shaft, type P 600N (1”3/8 Z6 tractor side)
- PTO drive shaft, type P 600N (1”3/4 Z6 tractor side)
- PTO drive shaft, type P 600N (1”3/4 Z20 tractor side)
- PTO drive shaft, type P 600N (1”3/8 Z21 tractor side)
