SOLE
15-25 HP
DISPLACEABLE ROTARY TILLER
SOLE is a movable hoe designed for tractors with power ranging from 15 to 25 HP. It is equipped with a Cat. 0-I attachment point and has a single-speed gearbox at 540 rpm, with a rotor operating at 240 rpm.
Transmission is guaranteed by a cardan joint with safety bolt and a side chain transmission with automatic chain tensioner, while sideways movement is manual. The machine is equipped with depth-adjustable slides and CE safety guards for safe and efficient working.
SOLE
DISPLACEABLE ROTARY TILLER
STANDARD EQUIPMENT
- 3-point linkage Cat. 0-I.
- Single-speed gearbox, PTO 540 rpm.
- Rotor speed 240 rpm.
- PTO drive shaft with shear bolt.
- Chain transmission.
- Automatic chain adjuster.
- Rotor flanges with 4 spiral C-blades (mounted outwards).
- Manual side-shift.
- Side skids for depth adjusting.
- Accident prevention protections according to CE directives.
