AF/REV

AF/REV

potenza
40-100 hp
diametro
5-6 cm

MULCHERS FOR VINEYARD AND ORCHARD

The AF/REV Berti is a professional mulcher designed for tractors with power ratings between 40 and 100 HP. Compact yet sturdy, it is ideal for handling grass, vine shoots and prunings up to Ø 5–6 cm, always ensuring precise and uniform mulching.

The heart of the machine is the rotor, which can be configured with Berti type ‘P’ forged and heat-treated hammers or with the ‘YP’ blade kit, depending on operational requirements. This flexibility allows you to get the most out of both lighter jobs and the shredding of more substantial woody residues.

The AF/REV is designed for maximum ease of use: the Category I three-point hitch is double and mechanically adjustable, allowing for quick and secure attachment. It can be mounted at the front, rear or on reverse drive tractors, ensuring stability and adaptability in any working environment.

The rounded side design facilitates manoeuvring in vineyards and orchards without compromising cutting efficiency. In addition, there is a double freewheel in the gearbox, which reduces wear and tear and extends the life of the shredder. The height-adjustable levelling roller, equipped with a roller cleaner, offers further versatility in soil management.

Available in working widths from 105 to 220 cm, the Berti AF/REV mulcher is the perfect solution for vineyard and orchard owners looking for a reliable, durable and easy-to-use machine.

AF/REV
MULCHERS FOR VINEYARD AND ORCHARD

STANDARD EQUIPMENT

  • Double 3-point linkage (front and rear) Cat. I-II, displaceable on chrome tubes.
  • Double chassis.
  • Mechanical side-shift.
  • Chamfered profile on the right-end chassis corner.
  • Gearbox with Double free wheel.
  • Skids kit.
  • Full automatic belt tensioner.
  • Rear roller Ø 139, height adjustable, with scraper.
  • Forged and hardened BERTI hammers type “P” or “YP” blades.
  • Counter blades.
  • PTO 540 /1000 rpm (reverse pulleys).
  • Accident prevention protections according to EC directives.

ACCESSORIES ON REQUEST

  • Hydraulic side-shift with hoses and quick couplings
  • Kit collecting rakes
  • Centre-mount 3-point linkage (160-220)
  • Front metal wheels, height adjustable
  • Front protectors with chains
  • Rear roller Ø 159
  • Heavy duty rear roller Ø 159, with bolted end bearing housings
  • PTO drive shaft 50/1000 N(105-200)
  • PTO drive shaft 60/1000 N (220)

cutting tools

P
type P
YP
type YP
AF/REV
