EKR

EKR

potenza
30-100 HP
diametro
2-3 CM

MULCHER FOR GRASS AND SCRUBS

The ERK is a mulcher designed for professional maintenance of green areas, lawns, and parks, ideal for cutting grass and small woody residues up to 2–3 cm in diameter. Suitable for tractors from 30 to 100 HP, it offers versatility and excellent performance thanks to the possibility of fitting forged and hardened Berti flails of type L or A, or YL and YA blades, supported by internal counter-flails that optimize shredding quality.

The machine can be mounted at the rear or front and is also compatible with reverse guidance, providing maximum operational flexibility according to the needs of the farm or maintenance operator.

The ERK is available in six working widths – 125, 135, 145, 160, 180, and 200 cm – to adapt to different usage contexts and tractor types. It is equipped with a rear leveling roller of 139 mm diameter, which can be replaced upon request with 159 mm rollers featuring bolted end caps. Standard equipment includes a central attachment and gearbox with through shaft, ensuring robustness and long service life.

Optional features include support skids for greater ground stability and front chain guards to enhance safety during operation in demanding conditions.

EKR
MULCHER FOR GRASS AND SCRUBS

STANDARD EQUIPMENT

  • Fixed and reversible 3-point linkage, Cat. I (125-160).
  • Fixed and reversible 3-point linkage, Cat. II (180-200).
  • Top link tie rod.
  • Free wheel in the gearbox.
  • Gearbox with through shaft.
  • Rear roller Ø 139, self-cleaning, height adjustable (125-160)
  • Rear roller Ø 159, self cleaning, height adjustable (180-200).
  • Counter blades.
  • Forged and hardened BERTI hammers type “L” or “YL” blades (125-160).
  • Forged and hardened BERTI hammers type “A” or “YA” blades (180-200). PTO 540 /1000 rpm (reverse pulleys).
  • Accident prevention protections according to EC directives.

ACCESSORIES ON REQUEST

  • Skids kit
  • Front protectors with chains
  • Rear roller Ø 159, height adjustable, with bolted ends (180-200).
  • Gearbox PTO 540 rpm with double free wheel and through shaft
  • Gearbox PTO 1000 rpm with double free wheel and through shaft (
  • PTO drive shaft 50/1000 N
  • PTO drive shaft 60/1000 N

cutting tools

A
type A
YA
type YA
L
type L
YL
type YL
EKR
