PICKER/L

PICKER/L

potenza
60-100 CV
diametro
5 cm
PICKER/ L

Trinciatrice per residui di potatura di vigneto e frutteto

The PICKER®/L is the pick-up rotor shredder designed by Berti to ensure extra-fine processing of pruning residues. Ideal for vineyards, orchards and woody material up to Ø 5 cm, it ensures high performance even on cultivated or stony ground.
Robust and versatile, it can be used with tractors with power ratings between 35 and 80 HP, offering an efficient solution for the management of agricultural and forestry residues.

PICKER/L
Trinciatrice per residui di potatura di vigneto e frutteto

STANDARD EQUIPMENT

  • Fixed 3-point linkage, Cat. I.
  • Double chassis.
  • Top link tie rod.
  • Free wheel in the gearbox.
  • Pick-up rotor with mechanical transmission through self-lubricating chain.
  • Special heavy-duty torque limiter slip clutch in the “Pick-up” rotor’s transmission.
  • Full automatic belt tensioner.
  • Rear grid Ø 40 for discharge through, in wear-resistant material.
  • Counter blades.
  • Forged and hardened BERTI hammers type “P”.
  • Frontal conveying guards.
  • Set steering wheels, pneumatic.
  • PTO 540 rpm.
  • Accident prevention protections according to EC directives.

ACCESSORIES ON REQUEST

  • Pick-up rotor with extra-quantity of teethKit collecting spikes, frontal
  • Hydraulic transmission of pick-up rotor and speed regulator
  • Kit steering wheels of solid rubber
  • PTO drive shaft 60/800 N
  • PTO drive shaft 60/1000 N

cutting tools

Mazze “P”

P
type P
PICKER/L
