TA/S

TA/S

potenza
80-120 hp
diametro
7-8 CM

For ditches, banks of watercourses, road side banks

TA/S is a mulcher designed for managing embankments, ditches and roadside verges, compatible with tractors from 80 to 120 HP. It is ideal for shredding grass and shrubs up to a maximum diameter of 7-8 cm and is available in working widths of 160, 180, 200, 220 and 250 cm.

The machine is equipped with a gearbox external to the machine body, which allows for greater reach to the right, enabling safe working even in the deepest ditches. On flat ground, the TA/S remains off-centre in relation to the tractor, ensuring greater stability and precision.

The tractor attachment is rear, with a fixed Category II three-point hitch and automatic belt tensioner. The double Strenx body, with rounded inner sides, ensures strength and durability. The machine is also equipped with hydraulic tilt via a floating system with safety valves and a levelling roller with roller cleaner, for uniform working on all types of terrain.

The rotor can be fitted with A hammers or YA knives and is equipped with counter hammers, ensuring effective and precise shredding. On request, the TA/S can be equipped with the Berti patented anti-shock system for shock absorption and the X-FLOAT, the hydraulic jack for floating tilt that optimises field operations and ensures accurate control. A left-hand version of the machine is also available.

Optional extras include skids, chain or rubber front guards, roller replacement with bolted bells, double-acting distributor, road clearance stickers and road transport kit, to increase versatility, safety and ease of use.

TA/S
For ditches, banks of watercourses, road side banks

STANDARD EQUIPMENT

  • 3-point linkage Cat. II, with floating system and safety lock.
  • Double chassis.
  • Chamfered profile on the right-end chassis corner.
  • Gearbox position externally to the machine body.
  • Free wheel in the gearbox.
  • Full automatic belt tensioner.
  • Hydraulic side shift with safety valve.
  • Hydraulic cylinder with floating link and safety valve.
  • Rear roller Ø 159, height adjustable.
  • Counter blades.
  • Forged and hardened BERTI hammers type “A” or “YA” blades.
  • PTO 540 rpm.
  • PTO drive shaft, Walterscheid®.
  • Accident prevention protections according to EC directives.

ACCESSORIES ON REQUEST

  • Anti-Shock Device (BERTI patent)
  • Hydraulic tilt with Berti floating system “X-FLOAT”
  • Skids kit
  • Front protectors with chains and rubber
  • Heavy duty rear roller Ø 159, with bolted end bearing housings
  • Left-Hand version
  • Double effect distributor with 2 levers and wire-cables
  • Electronic hour meter, vibration
  • Road sign stickers
  • Kit for transporting the mounted machine (in vertical position)
  • Wide-Angle PTO Drive Shaft 80/1750, Walterscheid®

cutting tools

A
type A
YA
type YA
TA/S
