TA/PS
For ditches, banks of watercourses, road side banks
TA/PS is a mulcher designed for managing embankments and ditches, compatible with tractors from 90 to 200 HP. It is ideal for shredding grass and shrubs up to 10 cm in diameter, available in working widths of 180, 200, 220 and 250 cm.
The machine is equipped with an external gearbox, which allows for greater reach to the right, ensuring safety when working in ditches. On flat ground, the TA/PS remains well off-centre from the tractor, optimising stability and manoeuvrability.
The Category II three-point linkage is fixed and equipped with a safety system, while the automatic strap tensioner ensures maximum operating efficiency. The double Strenx box, with rounded internal corners on the sides, offers strength and durability even in the most demanding conditions. The machine is rear-mounted to the tractor and features hydraulic tilt via a floating system with safety valves. The levelling roller with roller cleaner completes the standard equipment. The rotor can be fitted with A hammers or YA knives and is equipped with counter hammers.
On request, the TA/PS can be equipped with the Berti patented anti-shock system to absorb shocks and protect the frame, and with the X-FLOAT, the hydraulic jack for floating tilt, which optimises field operations and ensures precise and reliable control. A left-hand version of the machine is also available.
Optional extras include skids, chain and rubber front guards, roller replacement with bolted bells, front frame guard, double-acting distributor, road clearance stickers and road transport kit.
STANDARD EQUIPMENT
- 3-point linkage Cat. II, with floating system and safety lock.
- Double chassis.
- Chamfered profile on the right-end chassis corner.
- Gearbox position externally to the machine body.
- Free wheel in the gearbox (1”-3/4, Z6, input shaft).
- Full automatic belt tensioner.
- Hydraulic side shift with safety valve.
- Hydraulic cylinder with floating link and safety valve.
- Rear roller Ø 159, height adjustable.
- Counter blades.
- Forged and hardened BERTI hammers type “A” or “YA” blades.
- PTO 540 rpm.
- Wide-Angle PTO Drive Shaft, Walterscheid®.
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Anti-Shock Device (BERTI patent)
- Hydraulic tilt with Berti floating system “X-FLOAT”
- Skids kit
- Front protectors with chains and rubber
- Heavy duty rear roller Ø 159, with bolted end bearing housings
- Left-Hand version
- PTO 1000 rpm, (1″-3/4 input shaft)
- Cat. 3 pins for low links
- Double effect distributor with 2 levers and wire-cables
- Electronic hour meter, vibration
- Shock-proof bar, in front position
- Road sign stickers
- Kit for transporting the mounted machine (in vertical position)
cutting tools
