TA/MI

TA/MI

potenza
50-100 hp
diametro
4-5 CM

For ditches, banks of watercourses, road side banks

TA/MI is the Berti mulcher designed for managing embankments, ditches, roadside verges, as well as vineyards and orchards, thanks to the internal position of the gearbox.

It is compatible with tractors from 50 to 100 HP. It is suitable for shredding grass and small woody debris up to a maximum diameter of 4-5 cm and is available in working widths of 145, 160, 180 and 200 cm.

The machine is built with an internal gearbox, ideal for mixed use, and features a double Strenx casing with rounded sides to ensure strength and safety during operation, even on difficult terrain. The tractor attachment is rear, with a fixed category II three-point hitch, automatic belt tensioner and hydraulic tilt via a floating system with safety valves.

The rotor can be equipped with P hammers or YP knives, ensuring uniform and effective shredding. On request, the machine can be equipped with the Berti patented anti-shock system, which absorbs shocks and protects the frame, and a left-hand version can be produced for special operations. Optional extras include skid kits, double-acting distributors, front chain guards, road clearance stickers and kits for transporting the machine in a vertical position, increasing versatility, safety and ease of use.

TA/MI
For ditches, banks of watercourses, road side banks

STANDARD EQUIPMENT

  • 3-point linkage Cat. II, with floating system and safety lock.
  • Double chassis.
  • Chamfered profile on the right-end chassis corner.
  • Gearbox position internally to the machine body.
  • Free wheel in the gearbox.
  • Full automatic belt tensioner.
  • Hydraulic side shift with safety valve.
  • Hydraulic cylinder with floating link and safety valve.
  • Rear roller Ø 139, height adjustable.
  • Counter blades.
  • Forged and hardened BERTI hammers type “P” or “YP” blades.
  • PTO 540 rpm.
  • PTO drive shaft, Walterscheid®.
  • Accident prevention protections according to EC directives.

ACCESSORIES ON REQUEST

  • Anti-Shock Device (BERTI patent)
  • Skids kit
  • Front protectors with chains
  • Left-Hand version
  • 3-point linkage, Cat. I
  • Kit Double effect distributor with 2 levers and wire-cables
  • Road sign stickers
  • Kit for transporting the mounted machine
  • Wide-Angle PTO Drive Shaft 60/1750, Walterscheid®

cutting tools

P
type P
YP
type YP
TA/MI
