TA/MF
For ditches, banks of watercourses, road side banks
TA/MF is a medium-heavy shredder designed for front, rear or reversible use. When attached to the front, it can be used in combination with a rear brush cutter arm, significantly increasing productivity.
It is compatible with tractors from 150 to 250 HP and is suitable for shredding grass and shrubs up to 4-5 cm in diameter, available in working widths of 160, 180, 200 and 220 cm.
The machine features a fixed Category II three-point hitch with safety system and an automatic belt tensioner. The double Strenx frame, with rounded internal corners on the sides, guarantees strength and durability even in the most demanding conditions. Hydraulic tilt is managed by an X-FLOAT floating system with safety valves, and the levelling roller is equipped with a roller cleaner.
The functions are controlled electrically via a joystick, while the rotor can be fitted with P hammers or YP blades and is equipped with counter hammers. The shredder also includes a torque limiter, front chain and rubber guards and a road signage kit.
On request, it is possible to add skids, double three-point hitch, roller with bolted bells and stabiliser roller, to adapt the machine to specific field and transport requirements.
STANDARD EQUIPMENT
- 3-point linkage Cat. I-II with mech. breakaway.
- Double chassis.
- Chamfered profile on the right-end chassis corner.
- Gearbox with Double free wheel and through shaft.
- Full automatic belt tensioner.
- Hydraulic side-shift on chrome tubes.
- Hydraulic height adjustment of the main frame, with floating system.
- Hydraulic tilt with Berti floating system “X-FLOAT” and safety lock-valve.
- Electrohydraulic controls, with joystick.
- Rubber flex-coupling in the transmission.
- Rear roller Ø 139, self-cleaning, height adjustable.
- Counter blades, bolted.
- Forged and hardened BERTI hammers type “P” or “YP” blades.
- Front protectors by chains and rubber.
- Kit road-warning panels with lights.
- PTO 1000 rpm.
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Skids kit
- Double 3-point linkage (front/rear) assembly
- Kit stabilizing roller Ø 273 with scraper, underneath the main frame
- Heavy duty rear roller Ø 159, with bolted end bearing housings
- PTO drive shaft 80/1000 N (1″-3/8 Z6 tractor side)
