TA/K
For ditches, banks of watercourses, road side banks
The TA/K is a shredder designed for managing embankments and ditches, compatible with tractors from 30 to 50 HP. It is suitable for shredding grass and small woody residues up to a maximum diameter of 2 cm and is available in working widths of 115, 125 and 145 cm.
The machine is equipped with a gearbox inside the machine body, ensuring protection and reliability of the transmission system. The tractor attachment is rear, with a fixed Category I three-point hitch and integrated safety system. The TA/K also features hydraulic tilt via a floating system with safety valves, allowing for simple and safe adjustment when working on uneven ground.
The rotor can be equipped with G-type hammers, ensuring effective and uniform shredding. On request, front chain guards and double-acting distributors can be added, increasing the machine’s versatility and operational safety.
STANDARD EQUIPMENT
- 3-point linkage, Cat. I.
- Gearbox position internally to the machine body.
- Free wheel in the gearbox.
- Hydraulic side shift with safety valve.
- Hydraulic cylinder with floating link and safety valve.
- Full automatic belt tensioner.
- Skids kit.
- Mechanical breakaway-system.
- Rear roller Ø 114, height adjustable.
- Forged and hardened BERTI hammers type “G”.
- PTO 540 rpm.
- PTO drive shaft, Walterscheid®.
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Front protectors with chains
- Double effect distributor with 2 levers and wire-cables
- Wide-Angle PTO Drive Shaft, Walterscheid®
cutting tools
