FB/X
COMPACT RANGE FOR HEDGE CUTTING
The FB/X is a hedge trimmer, suitable for tractors with 20-30 HP, with a cutting diameter of up to 2 cm. The machine is equipped with a 150 cm hedge bar, complete with a super-rotation plate, which allows it to easily adapt to different working angles.
The coupling is directly between the pump and the tractor’s power take-off, without the use of a cardan shaft, and allows operation in both reverse left and front positions.
It is equipped with an independent hydraulic system with remote controls, via flexible CVI and 4 levers, which guarantee precision and safety. The blades are stabilised with a fixing support, and the mechanical spring safety system protects the arm in the event of impact.
Furthermore, upon request, the trimmer can be equipped with anti-tilt support wheels, electric on/off controls and sensing with mini joystick, knife blades or whistles and a grass cutting plate.
STANDARD EQUIPMENT
- 3-point linkage, Cat. I.
- Independent hydraulics.
- Direct coupling pump-PTO of the tractor (no drive shaft).
- Locking tie rods with holding bracket.
- Cables controls with 4 levers.
- Hedge trimmer bar 150cm, with 360° articulation mount.
- Mechanical breakaway on the second arm.
- Possibility of front or reverse mounting (specify in the order).
- PTO 540 rpm.
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Kit of anti-tipping, pivoting wheels
- Oil cooler
- Electric controls, (ON/OFF), with Joystick and electric starter of the
- motor
- Electric controls “Load Sensing” with Joystick and electric starter of the motor
- Maxi joystick lever (in lieu of the std Mini).
- Inclinometer with display monitor (only with Load Sensing)
- Cutting bar with 6 blades 120cm (max Ø 3 cm.) with hoses
- Discs-cutter 3x Ø 500 – 120cm (max Ø 6 cm) with hoses
- Disc mower with 2 discs 105cm (max Ø 2 cm)
- Kit quick couplings (for boom and trimmer)
- Kit quick couplings for attachment
