FB/PG 320
HYDRAULIC BOOM MOWER WIHT PARALLEL GEOMETRY OF ARMS
FB/PG 320 is a parallelogram brush cutter designed for professional maintenance of grass and shrubs up to 3 cm in diameter. It can be attached to tractors with 40-60 HP and can work in reverse, on the left side or in the front position, offering great operational versatility.
The machine is equipped with an 80 cm head featuring direct transmission and a helical rotor fitted with Y-shaped articulated blades, with the option of reversing the direction of rotation to adapt to different working conditions. Inside the head there is a height-adjustable self-cleaning roller, while the removable bonnet facilitates maintenance. The equipment is completed by front and rear rubber guards. The 90° rotation of the arms and the parallelogram geometry ensure smooth movement and precision cutting.
The arm is also equipped with a hydraulic safety device with adjustable valve and a floating system on the head and first arm, ensuring perfect adaptation to the ground and greater stability during operation.
Among the optional extras, you can request the rear anti-collision bar with LED lights, electro-hydraulic suspension on the first arm, and electric on/off controls with a mini joystick sensing system to further increase comfort and operating precision.
STANDARD EQUIPMENT
- 3-point linkage, Cat 0-I.
- Independent hydraulics.
- Oil cooler.
- Rotation 90° of the arms.
- Parallel geometry of the arms frame.
- Locking tie rods with holding bracket.
- Flail head of 80 cm, type “LIGHT”.
- Reversible rotation of the rotor.
- Adjustable levelling roller on the flail head.
- Articulated “Y” blades.
- Cables controls with 5 levers.
- Hydraulic breakaway with adjustable valve.
- Floating system on the fi rst arm and on the rotor.
- Removable front hood of the flail head.
- Front and rear rubber protection of flail head.
- PTO 540 rpm.
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Shockproof rear bar with LED lights kit
- Flail head of 100 cm
- Kit 2Y + Bootie hammer
- Electro-hydraulic suspension (stepless) of the arms, only with “Load
- Sensing” controls
- Electric controls (ON/OFF) with Joystick and electric starter of the motor
- Electric controls “Load Sensing” with Joystick and electric starter of the motor
- Maxi joystick lever (in lieu of the std Mini)
- Left-Hand version
- Front mount version
- Trimmer 150 cm, with mount plate, motor and hoses
- Kit 360° articulation plate for trimmer bar
- Cutting bar with 6 blades, 120 cm (max Ø 3-4 cm), 360° articulation plate, hoses
- Discs-cutter 3x Ø 500 120 cm (max Ø 6cm), 360° articulation plate, hoses
- Kit quick complings for boom and mower head
- Kit quick couplings for attachment
- PTO drive shaft 50/1000 N
cutting tools
