FB/P SA 500-600
HYDRAULIC BOOM MOWER, RANGE WITH ADVANCED HEAD (RIGID)
FB/P SA 500-600 is a semi-advanced brush cutter designed for green management, ideal for cutting grass and shrubs up to 5 cm in diameter, applicable to tractors from 90 to 150 HP. The cutter head, available in sizes 100-120 cm, is equipped with direct transmission and a helical rotor fitted with Y-shaped articulated blades, with the possibility of reversing the direction of rotation. Inside the header there is a height-adjustable self-cleaning roller, while the bonnet is removable. The machine is protected by front and rear rubber covers and the arms rotate through 100°.
The FB/P SA 500-600 features a floating system on the head and first arm, a safety shock absorber with nitrogen accumulator and automatic return and a double oil filter for suction and discharge. There is also a second semi-advanced arm and a rear anti-collision bar with LED lights for greater protection and practicality during operations.
Among the available options, you can request the 125 cm headboard, electro-hydraulic and electro-pneumatic suspension on the first arm, electric on/off and load sensing controls with mini joystick, branch cutters and electric engine start.
STANDARD EQUIPMENT
- 3-point linkage Cat. II.
- Independent hydraulics.
- Shockproof rear bar with LED lights kit.
- Oil cooler whit thermostat.
- Central 100° pivoting arms frame.
- Second arm with advanced (rigid) shape for the head.
- Locking tie rods with holding bracket.
- Reversible rotation of the rotor.
- Adjustable levelling roller on the flail head.
- Articulated “Y” blades.
- Cable controls with 5 levers.
- Hydraulic breakaway with nitrogen accumulator and auto-return.
- Flail head 100 cm. (500), type “PRO” with helical disposition.
- Flail head 120 cm. (600), type “PRO” with helical disposition.
- Front and rear rubber protection of flail head.
- Removable front hood of the flail head.
- Floating system on the fi rst arm and on the rotor.
- Double filter – suction and exhaust.
- PTO 540 rpm.
ACCESSORIES ON REQUEST
- Double edge hammers
- Y-blades with fixed mount
- “Twist”-Blades
- Flail head 120 cm “PRO” with direct trasmission
- Flail head with belts transmission
- Flail head “PRO” with direct transmission
- Hydraulic adjustment of the head’s front hood, with hoses and quick couplings new
- Pneumatic suspension of the first arm
- Electro-hydraulic suspension (stepless) of the arms, only with “Load Sensing” controls
- Electric controls “ON/OFF” with Joystick
- Electric controls “Load Sensing” with Joystick
- Electric starter of the rotor
- Maxi joystick lever (in lieu of the std Mini)
- Left hand version
- 65 HP Gears-pumps
- 82 HP Piston-pumps, only with belts-transmission flail head
- Pruning Shear (max Ø 5 cm), with motor, hoses and flow control valve
- Mount plate for Pruning Shear new
- Kit quick couplings for boom and mower head
- Kit quick couplings for attachment
- Kit for road travel
- Stabilizer rigid frame kit (for tractor), with quick release. Made to measure
- PTO drive shaft 60/1000 N
