FB/P A.H.G. 500-600
HYDRAULIC BOOM MOWER, WITH ADVANCED HEAD (HYDRAULIC)
FB/P A.H.G. 500-600 is a brush cutter with hydraulic head feed, designed for green management and capable of cutting grass and shrubs up to 5 cm in diameter. It is compatible with tractors from 100 to 150 HP and available with a 100-120 cm head. The machine is equipped with direct transmission and a helical rotor fitted with Y-shaped articulated blades, with the possibility of reversing the direction of rotation. Inside the header there is a height-adjustable self-cleaning roller, while the bonnet is removable. The front and rear rubber guards ensure safety during use and the arms rotate up to 100°.
This version is equipped with a floating system on the head and first arm, a safety shock absorber with nitrogen accumulator and automatic return and a double oil filter for suction and discharge. It also has a second arm with hydraulic feed and oil-pneumatic suspension on the first arm, as well as a rear anti-collision bar with LED lights for added protection.
Among the available options, you can request the 125 cm head, electro-hydraulic and electro-pneumatic suspension on the first arm, load sensing electric controls with mini joystick, a trimmer, branch cutter, electric engine start and additional electro-hydraulic suspension on the first arm.
STANDARD EQUIPMENT
- 3-point linkage Cat. II.
- Independent hydraulics.
- Shockproof rear bar with LED lights kit.
- Oil cooler whit thermostat.
- Central 100° pivoting arms frame.
- Pneumatic suspension of the first arm.
- Locking tie rods with holding bracket.
- Reversible rotation of the rotor.
- Adjustable levelling roller on the flail head.
- Articulated “Y” blades.
- Cable controls with 6 levers.
- Hydraulic breakaway with nitrogen accumulator and auto-return.
- Flail head 100 cm. (500), type “PRO” with helical disposition.
- Flail head 120 cm. (600), type “PRO” with helical disposition.
- Front and rear rubber protection of flail head
- Removable front hood of the flail head.
- Floating system on the fi rst arm and on the rotor.
- Double filter – suction and discharge.
- PTO 540 rpm.
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Double edge hammers
- “Twist”-Blades
- Flail head 120 cm “MEDIUM” with direct trasnsmission
- Belt transmission
- Flail head 125 cm “PRO” with direct transmission
- Flail head 125 cm “PRO” with belt trasmission
- Hydraulic adjustment of the head’s front hood, with hoses and quick couplings
- Electro-hydraulic suspension (stepless) of the arms, only with “Load Sensing” controls
- Electric controls “Load Sensing” with Joystick
- Electric starter of the rotor
- Maxi joystick lever (in lieu of the std Mini)
- Left hand version
- 65 HP Gears-pumps
- 82 HP Piston-pumps, only with belts-transmission flail head
- Pruning Shear (max Ø 5 cm), with motor, hoses and flow control valve
- Mount plate for Pruning Shear
- Kit quick couplings for boom and mower head
- Kit quick couplings for attachment
- Kit for road travel
- Stabilizer rigid frame kit (for tractor), with quick release. Made to measure
- PTO drive shaft 60/1000 N
