FB/P 600
HYDRAULIC BOOM MOWER
FB/P 600 is a professional brush cutter designed for green space management, capable of cutting grass and shrubs up to 5 cm in diameter, suitable for tractors from 90 to 140 HP. The 120 cm cutter head is equipped with direct transmission and a helical rotor fitted with Y-shaped articulated blades, with the possibility of reversing the direction of rotation. Inside the head there is a height-adjustable self-cleaning roller, while the bonnet is removable. The machine is protected by front and rear rubber covers, and the arms rotate through 100°.
The FB/P 600 is equipped with a floating system on the head and first arm, a safety shock absorber with nitrogen accumulator and automatic return and a double oil filter for suction and discharge, to ensure safety and reliability during cutting operations.
Among the available options, you can request the 125 cm header, electro-hydraulic and electro-pneumatic suspension on the first arm, load sensing electric controls with mini joystick, trimming function, branch cutter and electric engine start.
STANDARD EQUIPMENT
- 3-point linkage Cat. II.
- Independent hydraulics.
- Oil cooler whit thermostat.
- Shockproof rear bar with LED lights kit.
- Central 100° pivoting arms frame.
- Locking tie rods with holding bracket.
- Reversible rotation of the rotor.
- Adjustable levelling roller on the flail head.
- Articulated “Y” blades.
- Cable controls with 5 levers.
- Hydraulic breakaway with nitrogen accumulator and auto-return.
- Flail head 120 cm., type “PRO” with helical disposition.
- Front and rear rubber protection of flail head
- Removable front hood of the flail head.
- Floating system on the fi rst arm and on the rotor.
- Double filter – suction and discharge.
- PTO 540 rpm.
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Double edge hammer
- Y-blades with fixed mount.
- “Twist”-Blades.
- Flail head with belts transmission
- Flail head 125 cm “PRO”
- Flail head 125 cm “PRO” with belts transmission
- Flail head 125 cm. type “FOREST” with belts transmission
- Hydraulic adjustment of the head’s front hood, with hoses and quick couplings
- Pneumatic suspension of the first arm
- Electro-hydraulic suspension (stepless) of the arms, only with “Load Sensing” controls
- Electric controls “Load Sensing” with Joystick
- Electric starter of the rotor
- Maxi joystick lever (in lieu of the std Mini)
- Left-Hand version
- Front mount version
- 65 HP Gears-pumps
- 82 HP Piston-pumps (only 1000 PTO), only with belts-transmission flail head
- Pruning Shear(max Ø 5 cm), with motor, hoses and flow control valve
- Mount plate for Pruning Shear
- Kit quick couplings for boom and mower head
- Kit quick couplings for attachment
- Kit for road travel
- Stabilizer rigid frame kit (for tractor), with quick release. Made to measure
- PTO drive shaft 60/1000 N
cutting tools
