FB/P 500-580
HYDRAULIC BOOM MOWER
The FB/P 500-580 professional brush cutter for green space management is designed for cutting grass and shrubs up to 5 cm in diameter and can be used on tractors from 80 to 120 HP. The 100 cm cutter head is equipped with direct transmission and a helical rotor fitted with Y-shaped articulated blades, with the possibility of reversing the direction of rotation. Inside the header there is a height-adjustable self-cleaning roller, while the header cover is removable. The machine is protected by front and rear rubber covers. The arms rotate through 100°, and the rotor can be equipped on request with double-edged hammers, fixed blades or half-turn blades.
The FB/P 500-580 features a floating system on the head and first arm, a safety shock absorber with nitrogen accumulator and automatic return and a double oil filter for suction and discharge, ensuring safety and reliability during use.
The available options include the 120 cm headboard, the addition of electro-hydraulic and electro-pneumatic suspension on the first arm, electric on/off and load sensing controls with mini joystick, the trimming function, branch cutter and electric engine start.
STANDARD EQUIPMENT
- 3-point linkage Cat. II.
- Independent hydraulics.
- Oil cooler whit thermostat.
- Shockproof rear bar with LED lights kit.
- Central 100° pivoting arms frame.
- Locking tie rods with holding bracket.
- Reversible rotation of the rotor.
- Adjustable levelling roller on the flail head.
- Articulated “Y” blades.
- Cable controls with 5 levers.
- Hydraulic breakaway with nitrogen accumulator and auto-return.
- Flail head 100 cm, type “PRO” with helical disposition.
- Front and rear rubber protection of flail head
- Removable front hood of the flail head.
- Floating system on the fi rst arm and on the rotor.
- Double filter – suction and exhaust and discharge.
- PTO 540 rpm.
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Double edge hammers
- Y-blades with fixed mount
- “Twist”-Blades
- Flail head 120 cm “PRO”
- Belt transmission
- Hydraulic adjustment of the head’s front hood, with hoses and quick couplings
- Pneumatic suspension of the first arm
- Electro-hydraulic suspension (stepless) of the arms, only with “Load Sensing” controls
- Electric controls “ON/OFF” with Joystick
- Electric controls “Load Sensing” with joystick
- Electric starter of the rotor
- Maxi joystick lever (in lieu of the std Mini)
- Left hand version
- Front mount version
- Trimmer 150 cm, with mount plate, motor and hoses
- Pruning Shear (max Ø 5 cm), with motor, hoses and flow control valve
- Mount plate for Pruning Shear
- Kit quick couplings for boom and mower head
- Kit quick couplings for attachment
- Kit for road travel
- PTO drive shaft 60/1000 N
