FB/G 300-300S-380-380S
HYDRAULIC BOOM MOWER
FB/G 300 – 300S – 380 – 380S is a brush cutter for cutting grass and small shrubs up to 2 cm in diameter, designed for tractors from 40-60 HP. It can be used in reverse, on the left side or at the front, ensuring maximum operational flexibility.
The 80 cm header is equipped with direct transmission and a helical rotor fitted with Y-shaped articulated blades, with the option of reversing the direction of rotation according to the requirements of the job. Inside the header there is a height-adjustable self-cleaning roller, while the header cover can be removed. The machine is also equipped with front and rear rubber guards to increase safety and protect the material.
The arm is equipped with a hydraulic safety device with adjustable valve and a floating system on the head and first arm to ensure stability and adaptation to the ground during use.
Among the optional extras, you can request anti-tip support wheels, additional suspension on the first arm, 100 cm headers, electric on/off controls with mini joystick sensing, and a blade kit with central hammer for the rotor, further increasing the machine’s versatility and efficiency.
STANDARD EQUIPMENT
- 3-point linkage, Cat. 0-I.
- Independent hydraulics.
- Oil cooler (only S version).
- Locking tie rods with holding bracket.
- Reversible rotation of the rotor.
- Adjustable levelling roller on the flail head.
- Articulated “Y” blades.
- Possibility of front,reverse or left hand mounting (specify in the order).
- Cables controls with 4 levers.
- Hydraulic breakaway with adjustable valve..
- Flail head 80 cm, type “LIGHT” with helical disposition.
- Floating system on the fi rst arm and on the rotor.
- Removable front hood of the flail head.
- Front and rear rubber protection of flail head.
- PTO 540 rpm.
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Shockproof rear bar with LED lights kit
- Oil cooler (standard equipment for “S” version)
- Flail head of 100 cm. Only for ”S” version
- Kit 2Y + Bootie hammer (head 80cm). Surcharge new
- Kit 2Y + Bootie hammer (head 100cm). Surcharge new
- Pneumatic suspension of the first arm
- Electro-hydraulic suspension (stepless) of the arms, only with “Load
- Sensing” controls
- Electric controls (ON/OFF) with Joystick and electric starter of the motor. Surcharge
- Electric controls “Load Sensing” with Joystick and electric starter of the motor. Surcharge
- Maxi joystick lever (in lieu of the std Mini) new
- Trimmer 150 cm, with mount plate, motor and hoses
- Kit 360° articulation plate for trimmer bar new
- Cutting bar with 6 blades, 120 cm (max Ø 3-4 cm), 360° articulation plate, hoses
- Discs-cutter 3x Ø 500 120 cm (max Ø 6cm), 360° articulation plate, hoses
- Kit quick couplings for boom and mower head (300-380)
- Kit quick couplings for attachment (300-380)
- Kit quick couplings for boom and mower head (300 S – 380 S)
- Kit quick couplings for attachment (300 S – 380 S)
- PTO drive shaft 40/800 N
cutting tools
