FB/ARC STX 430-600
HYDRAULIC 3-PIECE BOOM MOWER (VINEYARD)
The FB/ARC STX 430–600 is a brush cutter designed for professional maintenance of grass and shrubs up to 2 cm in diameter, offering high performance and smooth operation even in demanding conditions. It is designed to be used with tractors from 80 to 100 HP, ensuring wide operational compatibility.
The machine is equipped with a 100 cm cutter head, featuring direct transmission and a helical rotor complete with Y-shaped articulated blades, with the possibility of reversing the direction of rotation according to the work requirements. Inside the head there is a height-adjustable self-cleaning roller, while the bonnet can be completely removed to facilitate maintenance and cleaning. The head is completed by front and rear rubber guards, designed for safety and to contain the cut material.
The arm offers a rotation of 95° and is equipped with a 70 cm telescopic arm, which significantly extends the operating range. The motor is positioned outside the head, a solution that promotes both heat dissipation and ease of inspection. The system is completed by a hydraulic safety device with adjustable valve, a floating system on the head and first arm, and a safety shock absorber with nitrogen accumulator and automatic return. There is also a double oil filter on the suction and discharge sides, ensuring greater reliability of the hydraulic system.
In addition to the standard equipment, the FB/ARC STX 430–600 can be enhanced with electro-hydraulic or electro-pneumatic suspension on the first arm, load sensing electric controls with mini joystick and trimmer, allowing the machine to be configured according to the most specific operational requirements.
STANDARD EQUIPMENT
- 3-point linkage Cat. II.
- Independent hydraulics.
- Oil cooler.
- Shockproof rear bar with LED lights kit.
- Central 95° pivoting arms frame.
- Locking tie rods with holding bracket.
- Reversible rotation of the rotor.
- Adjustable levelling roller on the flail head.
- Articulated “Y” blades.
- Cable controls with 7 levers.
- Telescopic extension cm. 70 (430) and 120 cm. (600).
- Hydraulic breakaway on the third arm (430).
- Hydraulic breakaway with nitrogen accumulator and auto-return (600).
- Flail head 100 cm type “LIGHT” (max. Ø 3 cm.).
- Motor placed in the far outside of the head.
- Front and rear rubber protection of flail head.
- Removable front hood of the flail head.
- Floating system on the fi rst arm and on the rotor.
- Double filter – suction and exhaust.
- PTO 540 rpm.
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Flail head 80 cm with direct transmission, type “LIGHT”. Surcharge
- Kit 2Y-blades + Bootie hammer-flail
- Pneumatic suspension of the first arm
- Electro-hydraulic suspension (stepless) of the arms, only with “Load
- Sensing” controls
- Electric controls “Load Sensing” with Joystick and electric starter of the motor
- Maxi joystick lever (in lieu of the std Mini) new
- Trimmer 150 cm, with mount plate, motor and hoses
- Kit 360° articulation plate for trimmer bar new
- Cutting Bar 160 cm with 8 blades (max Ø 3-4 cm), 360° articulation plate, hoses
- Discs-cutter 4x Ø 500, 160 cm (max Ø 6cm), 360° articulation plate, hoses
- Kit quick couplings for boom and mower head
- Kit quick couplings for attachment
- PTO drive shaft 50/1000 N
