FB/ARC STX 380
HYDRAULIC 3-PIECE BOOM MOWER (VINEYARD)
FB/ARC STX 380 is a brush cutter designed to guarantee effective work on grass and shrubs up to 3 cm in diameter, offering high performance while maintaining a compact and agile structure. It is suitable for tractors from 60 to 90 HP, ensuring versatility both on farms and in professional green space maintenance.
The machine incorporates an 80 cm head, featuring a direct drive that ensures maximum efficiency and a helical rotor equipped with Y-shaped articulated blades, with the possibility of reversing the direction of rotation depending on the type of operation. Inside the head is a height-adjustable self-cleaning roller, while the removable bonnet facilitates inspection and maintenance. There are also front and rear rubber guards, designed to work safely even in sensitive areas. The arm structure allows for rotation up to 95° and incorporates a 60 cm telescopic arm, which significantly increases the operating range. The head motor is positioned externally, a choice that improves heat dissipation and accessibility.
In terms of operator and machine protection, the FB/ARC STX 380 is equipped with a hydraulic safety device with adjustable valve, while the floating system acts on both the head and the first arm, ensuring optimal adaptation to the ground. The technical features are completed by a double oil filter on the intake and exhaust, which improves the reliability of the hydraulic circuit during the most demanding operations.
In addition to the standard configuration, the machine can be enhanced with various optional solutions: electro-hydraulic or electro-pneumatic suspension on the first arm, load sensing electric controls with mini joystick, trimmer, as well as rear impact bar with LED lights, particularly useful in road works or in low visibility conditions.
STANDARD EQUIPMENT
- 3-point linkage Cat. I.
- Independent hydraulics.
- Oil cooler.
- Central 95° pivoting arms frame.
- Locking tie rods with holding bracket.
- Reversible rotation of the rotor.
- Adjustable levelling roller on the flail head.
- Articulated “Y” blades.
- Cable controls with 7 levers.
- Telescopic extension cm. 60.
- Hydraulic breakaway on the third arm.
- Flail head 80 cm type “LIGHT” with helical disposition.
- Motor placed in the far outside of the head.
- Front and rear rubber protection of flail head.
- Removable front hood of the flail head.
- Floating system on the fi rst arm and on the rotor.
- Double filter – suction and exhaust.
- PTO 540 rpm.
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Shockproof rear bar with LED lights kit
- Kit 2Y-blades + Bootie hammer-flail (head 80 cm) new
- Pneumatic suspension of the first arm
- Electro-hydraulic suspension (stepless) of the arms, only with “Load
- Sensing” controls
- Electric controls “Load Sensing” with Joystick and electric starter of the motor
- Maxi joystick lever (in lieu of the std Mini) new
- Trimmer 150 cm, with mount plate, motor and hoses
- Kit 360° articulation plate for trimmer bar new
- Cutting bar with 6 blades, 120 cm (max O 3-4 cm), 360° articulation plate, hoses
- Discs-cutter 3x Ø 500 120 cm (max Ø 6cm), 360° articulation plate, hoses
- Kit quick couplings for boom and mower head
- Kit quick couplings for attachment
- PTO drive shaft 50/1000 N
