KX
FORESTRY MULCHER WITH FIXED TOOTH ROTOR
The KX is a fixed hammer forestry mulcher, designed for clearing uncultivated land, undergrowth and plant residues up to 12-15 cm in diameter. Available in working widths of 150, 170 and 190 cm, it is suitable for tractors with power ratings between 60 and 110 HP. The mulcher can be attached to the tractor at the front or rear and is also suitable for reverse driving.
The machine features a fixed three-point hitch, a double HARDOX box, a rear bonnet with hydraulic opening and closing, adjustable skids and screw-on counterweights. The automatic belt tensioner ensures optimum transmission at all times.
The SmoothCut forestry rotor has a diameter of 360 mm and is equipped with fixed XF2 tools made of wear-resistant material, ensuring effective cutting even on the most resistant wood. Among the available options, a mechanical or hydraulic felling bow can be added to increase safety and practicality during forestry operations.
STANDARD EQUIPMENT
- Fixed 3-point linkage, Cat. I-II.
- Double chassis.
- Double free wheel in the gearbox.
- Full automatic belt tensioner.
- Rear hood with hydraulic adjustment.
- Skids kit, height adjustable, with anti-wear shoe.
- Fixed tooth rotor, Berti “SMOOTH-CUT”, Ø 360.
- Counter blades, bolted.
- Fixed tooth Berti “XF2”, with tungsten carbide tips.
- PTO 540 rpm (1000rpm on request).
- Accident prevention protections according to EC directives.
ACCESSORIES ON REQUEST
- Mech. guard/push frame
- Hydr. guard/push frame
- Extension kit for 3-point linkage
- Electronic hour meter, vibration
- PTO drive shaft, type 80/1000N (1”3/8 Z6 tractor side)
- PTO drive shaft 80/1300 with slip clutch (1″-3/8 Z6 tractor side)
- PTO drive shaft 80/1000 with cam clutch (1″-3/8 Z6 tractor side)
cutting tools
