EFX/MD

EFX/MD

potenza
90-160 hp
diametro
20 CM

FORESTRY MULCHER WITH FIXED TOOTH ROTOR

The EFX/MD is a fixed hammer forestry mulcher, designed for clearing uncultivated land, undergrowth and plant residues up to 20 cm in diameter. It is available in working widths of 160, 180, 200 and 220 cm and is compatible with tractors from 90 to 160 HP.

The machine features a fixed three-point hitch, double body in STRENX and HARDOX, rear bonnet with hydraulic opening and closing, adjustable skids and screw-on counterweights, with automatic belt tensioner to ensure efficiency and operational continuity.

The Forestale SmoothCut rotor, with a diameter of 440 mm, can be equipped with fixed XF1 double plate hammers made of wear-resistant material, ensuring effective and long-lasting cutting. Optional extras include a mechanical or hydraulic deflector, front and rear conveyor blades and a centrifugal clutch, which allows the rotor to start gradually for increased safety and control during use.

EFX/MD
FORESTRY MULCHER WITH FIXED TOOTH ROTOR

STANDARD EQUIPMENT

  • Fixed 3-point linkage, Cat. I-II.
  • Double chassis.
  • Double free wheel in the gearbox, with 1” 3/4 Z6 input shaft.
  • Full automatic belt tensioner.
  • Rear hood with hydraulic adjustment.
  • Skids kit, height adjustable, with anti-wear shoe.
  • Fixed tooth rotor, Berti “SMOOTH-CUT”, Ø 440.
  • Counter blades.
  • Fixed tooth Berti “XF1”, with tungsten carbide tips.
  • PTO 1000 rpm (PTO 540 rpm on request).
  • Accident prevention protections according to EC directives.

ACCESSORIES ON REQUEST

  • Mech. guard/push frame
  • Hydr. guard/push frame
  • Conveyor guards (front and rear)
  • Centrifugal clutch (BERTI design)
  • Electronic hour meter, vibration
  • PTO drive shaft, type 80/1000N (1”3/8 Z6 tractor side)
  • PTO drive shaft, type 80/1000N (1”3/4 Z6 tractor side)
  • PTO drive shaft, type 80/1000N (1”3/4 Z20 tractor side)
  • PTO drive shaft, type 80/1000N (1”3/8 Z21 tractor side)
  • PTO Drive Shaft 80/1000, with cam clutch (1”-3/8 Z6, tractor side)
  • PTO Drive Shaft 880/1000, with cam clutch (1”-3/4 Z6, tractor side)
  • PTO Drive Shaft 80/1000, with cam clutch (1”-3/4 Z20, tractor side)
  • PTO Drive Shaft 80/1000, with cam clutch (1”-3/8 Z21, tractor side)

cutting tools

XF1
type XF1
EFX/MD
