PARK/SB
Hydraulic mulching head for mini-excavators
The PARK/SB hydraulic brush cutter is designed for mini-excavators with an operating weight between 6 and 8 tonnes and is suitable for cutting grass and brambles up to Ø 6 cm.
It is available in two sizes: 90 and 110 cm. The machine is constructed with a double Strenx casing, side belt transmission, support skids and a levelling roller, which also provides support. The cast iron hydraulic gear motor is equipped with external drainage via the Berti Fluid Box, ensuring reliability and durability even in the most demanding conditions.
The helical rotor is equipped with counter-hammers and can be fitted with BERTI type “D” forged and tempered hammers or the type “YB” knife kit, depending on operational requirements.
The available options include a customised attachment saddle complete with pins, a non-drainage motor, ON/OFF or proportional solenoid valves for accessories with a function and push-button panel, and a hydraulic swivel head with pipes, to ensure maximum versatility in the field.
This machine combines robustness, precision and safety, making it ideal for professional green maintenance work on large areas or complex terrain.
STANDARD EQUIPMENT
- Double chassis.
- Belts trasmission.
- Height adjustable levelling rollerØ 139 mm.
- Side skids with wear undershoes.
- Forged and hardened BERTI hammers type “D” or BERTI blades type “YB”
- Counter blades
- Self-levelling support for mount hitch.
- Hydraulic cast iron gear motor with drain line.
- Hydraulic valves block “Berti Fluid Box” (max 120 lt/min).
- Hydraulic hoses with explosion-proof sheats (L= 3,00 mt.)
- Under plate for mount hitch.
- Accident prevention protections according to EC directives
ACCESSORIES ON REQUEST
- Mount hitch & pins, made to measure
- Factory application of your adapter for quick hitch (EU only)
- Hydraulic rotation device with hoses (without self-levelling support for mount hitch)
- Kit Diverter Valve, ON/OFF, for 1 additional function with button panel
- Kit Diverter Valve, Proportional-Auxiliary, for 1 additional function with button panel
- Motor without drain line ( max 15 bar pressure on return)
- Walking foot kit
cutting tools
models
